This powerful 42" three-head planer sander is purpose-built for high-efficiency processing of solid wood components. Featuring a spiral insert cutterhead, it delivers superior surface quality while using less horsepower than traditional straight-knife systems. Heavy-duty cast-iron construction ensures stability and longevity, making it the perfect fit for continuous-use and high-production environments. An intuitive touchscreen interface and integrated safety features round out this robust solution.
Key Features & Benefits
Heavy-Duty Industrial Build
• Constructed with premium cast-iron components for superior durability
• Engineered to withstand demanding, high-output operations
• Dampens vibration for smoother, more precise performance
Efficient Spiral Cutterhead Technology
• Spiral insert cutterhead provides excellent finishes with reduced power consumption
• Knives can be rotated for extended service life
• Delivers optimal material removal and smooth surface results
User-Friendly Touchscreen Control
• Easily adjust feed speed, thickness, and motor settings
• Intuitive touch panel streamlines setup and operation
• Boosts operator efficiency and reduces downtime
Maximized Productivity with Three-Head Design
• Planer head followed by dual sanding heads for faster throughput
• Minimizes grit changeovers for uninterrupted operation
• Ensures consistent sanding across various materials
Advanced Operator Safety
• Emergency stops at infeed, outfeed, and access points
• Anti-kickback device for added cutterhead protection
• Interlocking access doors enhance operational safety
- Net Weight: 9,259 lbs. (4200 kg)
- Shipping Weight: 10,031 lbs. (4550 kg)
- Belt Size: 43" x 75"
- Compressed Air Requirements: 85 PSI (6 Kg/cm2)
- Dust Collection Requirements: 8,063 CFM (13,700 M3/HR)
- Electrical Requirements: 460/3/60 = 100 Amps
- Feed Belt Speed: 13 - 59 FPM (4 to 18 m/min)
- Feed Motor: 3 HP
- Machine Dimensions: 98" x 71" x 79" (2500 x 1820 x 2025 mm)
- Min/Max Working Thickenss: 4.7" (120 mm)
- Min. Part Length: 16.9" (430 mm)
- Motor: 25 HP /25 HP /20 HP
- No. Of Heads: 3
- Shipping Dimensions: 115" x 79" x 82" (2930 x 2030 x 2090 mm)
- Table Rise/Fall Motor: 1 HP
- Working Width: 42" (1066 mm)
