The Hoffmann W1031000 Dovetail Machine is a high-performance, manually operated routing system built to deliver single dovetail keyways with precision and consistency. Designed for professional woodworking applications, this machine combines rugged construction with ease of use, making it perfect for cabinet components, miter joints, and other fine joinery. Every feature supports smooth operation, precise results, and long-term reliability.
Key Features & Benefits
Precision Engineering for Long-Term Performance
• Built to last, even in demanding workshop environments.
• Provides a large, stable workspace for improved comfort and efficiency.
• Enables smooth, accurate routing motion for consistent results.
Simple Setup and Manual Control
• Allows accurate positioning of the keyway location.
• Lets you easily set routing height for perfect dovetail lengths.
• Operates independently without compressed airflexible and portable.
Efficiency-Boosting Design
• Quickly secures materials for faster workflow and minimal downtime.
• Delivers up to 10,000 strokes for long-lasting, clean cuts.
• Enhances speed and accuracy by adjusting to your material flow.
Clean & Safe Operation
• Connects to shop vacuums for a dust-free workspace.
• Stabilizes workpieces for safe and accurate routing.
• Adds extra protection during operation.
Expandable and Customizable
• Add capacity for larger or longer pieces.
• Included tool kit and jig make router bit changes fast and simple.
- Weight: 70.4 lbs
- Spindle Speed: 35,000 RPM
- Collet Size: 1/4"
- Motor Carriage Guides: 20mm diameter guide rods, precision ground
- Max. Routing Height: 3-3/8" - 5-1/8"
- Dust Port: 2"
- Power Supply: 120 volts – 7.4 Amps
- Motor: 885 Watt motor with double front bearing
- Operation: Manual dual action design
- Available Router Bits: W-0, W-1, W-2, W-3 (W-4 with optional motor)
- Dimensions: 29 1/8" x 25 5/8" x 32 3/4"
- Max. Height Moulding: 5 1/8" (130mm)
- Dust Collection Ports: 2" (50mm) diameter
- Installed Router Bit: W-2, solid carbide
