The Hoffmann W1032100 Dovetail Machine is a pneumatically controlled, high-precision routing system designed for efficiency and repeatability in professional woodworking environments. With advanced features like digital displays, automatic routing cycles, and robust construction, this machine is tailored for operations demanding high output and flawless dovetail joints across softwood, hardwood, and composite materials.
Key Features & Benefits
Fast & Accurate Pneumatic Routing
• Instantly secures the workpiece and reduces cycle time.
• Automatically guides the router up and down, keeping both hands free for better control.
• Provide precise readouts for keyway location and heightideal for repeatable, high-accuracy setups.
Heavy-Duty Construction for Industrial Use
• Offers vibration-free routing and extended durability.
• Ensures accurate cutter positioning and long-lasting performance.
• Engineered to handle demanding workloads with consistent results.
Operator-Friendly for Maximum Productivity
• Foot pedal control allows the operator to focus on positioning and safety.
• Speeds up job transitions and minimizes fatigue.
• Up to 16 strokes per minuteproduces two frames per cycle.
Integrated Dust Management
• Maintains a clean work area by connecting directly to a vacuum system.
• Reduces airborne dust and improves visibility during routing.
Versatile & Customizable
• Compatible with W-0 to W-4 keys (larger motor required for W-4).
• Ensures long bit life and high-quality cuts.
• Performs equally well with softwoods, hardwoods, and composites.
- Weight: 70.4 lbs
- Spindle Speed: 35,000 RPM
- Collet Size: 1/4"
- Motor Carriage Guides: 20mm diameter guide rods, precision ground
- Max. Routing Height: 3-3/4" - 5-7/8"
- Dust Port: 2"
- Power Supply: 120 volts – 7.4 Amps
- Motor: 885 Watt motor with double front bearing
- Air Supply: 90 psi – approx. 0.1 cubic foot/cycle
- Operation: Pneumatic – dual cylinder design
- Available Router Bits: W-0, W-1, W-2, W-3 (W-4 with optional motor)
- Dimensions: 29 1/8" x 25 5/8" x 32 3/4"
- Max. Height Moulding: 5 7/8" (150mm)
- Dust Collection Ports: 2" (50mm) diameter
- Installed Router Bit: W-2, solid carbide
