The SCM Morbidelli CX210 CNC Drilling Center is a compact, high-performance solution tailored for batch-1 processes. With the ability to drill, groove, and route on all five sides of the panel, this machine ensures continuous, efficient operation. Its automatic tool changes and advanced RO.AX spindle technology guarantee high precision, reduced downtime, and long-term reliability. Ideal for industries that demand flawless finishes, the CX210 features an automated panel return conveyor to optimize productivity during every cycle.
Key Features & Benefits
Superior Precision with RO.AX Spindle Technology
• Zero play during machining with rotation speeds up to 8000 rpm
• Reduced maintenance costs, five times lower than comparable systems
• Built for durability, offering long-lasting precision
Dual Drilling Heads for Increased Productivity
• Simultaneous machining with two drilling heads operating on independent Y and Z axes
• Automatic program management ensures smooth workflow, reducing manual input
• Up to 70% increased productivity by reducing machining time
Perfect Surface Finishes
• New worktable design ideal for delicate panels, preventing scratches and damage
• Provides a stable, secure surface to ensure high-quality results
• Works with a wide range of panel types, ensuring versatility
Optimized Cycle Time with Shaped Clamps
• No repositioning needed during drilling and routing operations
• Reduces cycle time and increases throughput
• Secure positioning ensures consistent precision throughout production
- Vertical Speed X-Y Axes: 70 m/min
- Routing Unit Available Tools On Tool Changer: 6
- Max. Workpiece Dimension: 3050 x 1300 x 95 mm
- 0-90-Deg Blade Unit Max. Rotation Speed: 5500 RPM
- Max. Panel Weight: 70 mm
- X-Y-Z Axes Speed (Max.): 70 - 40 - 30 mm/min
- Diameter: 125 mm
- Rotation Speed: up to 24000 RPM
- Motor: 7,5 kW
- Supply System: Water/ Vinyl Glue
- Available Tools On Tool Changer: 6
