The Cantek FR-200 Frame Saw is designed for precise and efficient cutting of solid wood into thin strips, making it ideal for high-volume production environments. With a powerful motor and a sensor-controlled feed system, this saw ensures accuracy and consistency across every cut. Its combination of feed and pressure rollers delivers smooth material movement through the cutting process, minimizing waste and maximizing yield. Whether you're working with hardwoods or engineered wood, the FR-200 ensures reliable performance day in and day out.
Key Features & Benefits
Sensor-Controlled Rollers for Smooth & Accurate Feeding
- Top front section features 7 pressure rollers and 3 air cylinders for consistent material hold-down
- Rear section includes 5 pressure rollers and 1 air cylinder, managed by a sensor to ensure proper feed pressure
- Sensor control adjusts pressure automatically, improving cut accuracy on varying material thicknesses
Multiple Feed Rollers for Continuous Operation
- 7 bottom feed rolls in the front section keep material moving steadily
- 5 bottom rolls in the rear section support exit and maintain material flow
- Designed for uninterrupted production, reducing operator handling and increasing throughput
Heavy-Duty Construction for Long-Term Reliability
- Industrial-grade frame ensures stability during operation, reducing vibration
- Precision-machined components offer long service life and minimal maintenance
- Built to perform in demanding production environments, whether you're cutting softwood or hardwood
- Blade Kerf: 1.2 mm
- Blade Pitch: 15
- Blade Size: 500 x40 x 0.8 mm
- Dust Outlet: 4 @ 5"
- Feed Speed: 0.1-2.0 m/min
- Finished Tolerance Value: ± 0.1 mm
- Main Shaft Speed: 480 RPM
- Max. Saw Blades: 24 Pieces
- Max. Working Thickness: 200 mm
- Max. Working Width: 150 mm
- Min. Precision Thickness: 2.0 mm
- Min. Working Length: 300 mm
- Min. Working Thickness: 60 mm
- Motor: 20 HP + 1/2 HP + 2 HP Blower
