The Cantek BM301 Horizontal Boring Machine is engineered for precision dowel hole drilling in door and furniture components. Designed with a dual-spindle head and adjustable center spacing, it ensures quick setup for various applications. Its durable cast iron construction and steel base deliver long-lasting performance. Pneumatic operation with foot pedal control adds efficiency and safety, while the 2HP direct drive motor provides consistent power for clean, accurate bores.
Key Features & Benefits
Pneumatic Controls Simplify Operation and Improve Safety
• Automatic drilling cycle is triggered via a foot pedal, allowing hands-free operation
• Workpiece is securely held in place with a pneumatic clamp during drilling
• Adjustable drilling speed enables optimal performance across material types
Adjustable Setup for Versatile Boring Applications
• Drill center spacing is adjustable from 0.71" to 3.93" (18–100 mm) for multiple dowel configurations
• Worktable height adjusts easily using a knob and threaded rod for different material thicknesses
• Depth of drilling is adjustable, with a maximum stroke of 4" (100 mm) to suit various project needs
Industrial Construction Ensures Accuracy and Longevity
• Drilling head and table are made from cast iron for stability and vibration reduction
• Mounted on a fabricated steel base for maximum rigidity and long-term durability
• 2 HP direct drive motor provides reliable power for fast, accurate horizontal drilling
- No. Of Spindles: 2
- Spindle Spacing: 0.71" - 3.93" (18 - 100 mm)
- Spindle Speed: 3450 RPM
- Work Table Dimensions: 15.75" x 10" (400 x 250 mm)
- Max. Drill Stroke: 4" (100 mm)
- No. Of Drills: 2 spindles
- Drill Bit Shank: 7/16"-14"
