The RITTER R853 is a dedicated, high-precision boring center built to handle both single and multiple-part operations with ease. With a robust 13-spindle configuration and the ability to drill in both horizontal and vertical orientations, this machine is ideal for drawer boxes, cabinetry, and more. Its ergonomic design and safety features ensure streamlined operation and reduced errors.
Key Features & Benefits
High-Precision Drilling with 13-Spindle Gear Driven Drill Head
• 13-Spindle Gear-Driven Drill Head
• 7 right-hand and 6 left-hand spindles for versatile configurations
• Ideal for multi-part, consistent hole placement in one cycle
Safety-Focused Operation
• Foot pedal activation allows hands-free control
• Emergency stop feature for immediate shutdown
• Dust clearance back fence helps reduce airborne particles
Flexible Horizontal & Vertical Drilling
• Adjustable fence system for different orientations
• Material clamps ensure secure, vibration-free drilling
• Perfect for diverse woodworking applications
Adjustable Depth Control for Customizable Drilling
• Adjustable boring depth turret gives users control over hole depth for various tasks
• Ensures precise drilling for different material thicknesses
• Speeds up the process by reducing the need for manual adjustments
Efficient Dust Collection for Clean Workspace
• Two dust collection ports help maintain a clean workspace and reduce mess
• Reduces the need for manual cleanup, improving efficiency
• Ensures a safer working environment by minimizing airborne dust
- Working Height: 34"
- Motor: 2 HP
- Spindle Centers: 32 mm
- Collet Size: 10 mm
- Max. Material Thickness: 0.75"
- Shipping Dimensions: 55" x 46" x 57"
- Max. Drawer Box Height: 14"
- Electrical: 230 V, 3 , 60 Hz, 5 A or 460 V, 3 , 60 Hz, 2.5 A
- Boring Depth Adjustment: 0-2"
- Footprint: 40" x 45"
- Shipping Weight: 1,005 lbs
- Table Area: 12" x 24"
- Air: 5 CFM at 80 – 100 PSI
- Weight: 1,077.000 lbs
