Dotul Door Stile & Rail Boring MT-104

The Door Master Model SDM-TM streamlines assembly of Mortise and Tenon Miter Doors and Cope and Stick Doors (90-deg). It delivers fast and precise clamping and squaring for large pantry doors to small drawer fronts.

• Size Range: Handles doors from 30" x 72" down to 5 ½" x 12 ½"
• Clamping: Standard model includes four clamps with sequential clamping system for streamlined workflow
• Pneumatic System: Features brand-name air valves and real double-action air cylinders for smooth, even pressure on door corners
• Door Inserts: Four slim inserts provide extra support for narrow door frames, paired with two-step pneumatic clamping for delicate frames
• Working Height: Adjustable pedestal allows for comfortable use and reduces operator strain
• Design: Ergonomic design with pneumatic system ensures smooth and efficient operation

• Model Number: 209.115.1 V2.5
• Working Thickness: 1/4"
• Feed Speed: 0-19 FPM
• Knife Motor: 1-1/2 HP
• Max. Profile: 9" x 6-3/4" x 3/4"
• Working Height: 35"
• Max. Height Above Final Cut: 3/16"
• Max. Stock Thickness: 7"
• Voltage: 115V (20 AMP REQUIRED)
• Phase: 1
• Heavy Gauge Steel Construction: 24" x 24" x 33"
• Guide System: 23 1/2" x 11 3/4" x 1/2", HDPE
• Planes Wide: 7"
• Min. Stock Length: 9"
• Overall Machine Dimensions: 24" x 24" x 50"
• Package Weight: 315 lbs
