This steel front fixing bracket with an expanding dowel mount attaches drawer fronts to Blum's LEGRABOX N-height side profiles. It is the system-matched component that carries the drawer front and provides the alignment adjustment that keeps gaps consistent across an installation.
The front fixing bracket is the interface between the drawer box and the visible front panel. In a LEGRABOX N-height drawer, the side profiles set the structure; this bracket clips to the front of those profiles and grips the drawer front through its expanding dowel. The result is a front that can be removed tool-free for cleaning or replacement and re-hung on the same clip without losing alignment. It is the right choice for production cabinet shops building N-height LEGRABOX drawers at volume and for single-project builders who want the same clip-and-adjust convenience that the LEGRABOX platform is built around.
The zinc finish reads as a clean, neutral silver that stays visible only at the bracket itself — tucked behind the drawer front in normal use. It pairs naturally with stainless or metallic interior hardware and suits drawer fronts in white, light gray, or natural wood tones where a warm or dark bracket finish would create an unwanted contrast. For installations specifying a darker interior — Orion Gray Matte LEGRABOX sides, for example — the Orion Gray Matte bracket finish may be the closer match; the zinc finish is the better call when the priority is a bright, neutral fixing point.
LEGRABOX front fixing brackets are height-specific and series-specific. This bracket is made for the N-height profile — 66.5mm tall — and will not align correctly on M, K, C, or F height LEGRABOX sides. Within the N-height program, the Expando mount requires a drilled bore in the drawer front to the diameter the Blum specification calls out; confirm the boring dimension from the LEGRABOX installation documentation before drilling. Cabinet shops running mixed heights on a single project should order brackets by height code for each run of drawers to avoid installation delays.
Yes. The non-handed bracket installs on either side, so a single part number covers both positions on the drawer. Confirm the quantity you need — typically two per drawer, one per side.
The Expando dowel presses into a pre-drilled bore in the drawer front, then expands to grip the material from inside. The front attaches and detaches cleanly without a fastener head showing on the front face, which matters on painted or high-gloss fronts where a screw hole would need filling.
No. This bracket is engineered for LEGRABOX N-height profiles. TANDEMBOX and other Blum systems use their own front fixing hardware, which is not interchangeable with LEGRABOX components.
Confirm the sold-as unit on this SKU before ordering. Most LEGRABOX front fixing brackets are sold individually; if that is the case here, order two per drawer.
Specifying the correct N-height bracket at the start of a LEGRABOX build means fronts hang straight, adjust without drama, and come off cleanly if a finish change is needed down the road.
Sold In: 1 Each
