The Leadermac 623 Platinum Moulder Series is engineered for high-production environments demanding superior finish quality, efficiency, and flexibility. Featuring spindle speeds up to 8,000 RPM, heavy-duty construction, and advanced electronic controls, the Platinum Series is ideal for applications where precision, speed, and durability are paramount.
Heavy-Duty, High-Precision Machine Structure
• Built from extra-heavy, heat-treated cast iron for maximum rigidity and vibration reduction, ensuring superior surface finish and extended tool life.
• Spindles are supported by four high-precision ABEC 7 bearings, allowing for high-speed operation with exceptional accuracy and longevity.
• Pneumatically controlled top feed rolls with independent pressure adjustments for infeed, midfeed, and outfeed rolls ensure smooth and consistent material feeding.
Advanced Machining Capabilities
• All spindles operate at 8,000 RPM, providing cleaner finishes and higher production speeds.
• Mechanical digital position indicators on radial and axial adjustments for all spindles, providing precise and repeatable setup changes.
• Available in 1 to 9 spindle configurations with optional working widths up to 13†and working thicknesses up to 10†for maximum versatility.
Intelligent Controls & Automation
• Full-feature touchscreen interface with history files, grinding room data downloads, and triple electronic position displays for setup efficiency and repeatability.
• Automates spindle positioning, minimizing setup times and operator error, improving throughput in high-production environments.
High-Efficiency Lubrication & Safety Systems
• Timed and volume-adjustable lubrication ensures smooth operation and reduced maintenance downtime.
• Grease lines to all main slideways and bearings are centralized for easy access and reliable lubrication
• Encloses the entire machine, reducing noise pollution and protecting the operator with interlocked safety switches and strobe-free lighting.
Includes
• Hard chrome tables and fences
• Maintenance free full cardan shaft drive to feedworks
• Cast iron frame for maximum stability & minimum vibration
• Includes 1 complete set of cutterheads including carbide spiral 1st bottom head & standard 4 knife heads
• Removeable left (operator) side, side head dust hood. Allows easy and full access to the side head for easy removal
• Side head pressure roller and chip breaker assembly on left (operator side) to include quick set wrench for adjustment, along with mechanical scale for easy setting, and consistent repeatability
- Working Thickness: 1/4" - 6"
- Finished Material Width: .6" - 9"
- Infeed Table and Fence: 78"
- Spindle Size: 13/16"
- Fence Height: 2.36"
