The GSlide GS2070 Plastic Rear Bracket is a dowel-mount rear support made specifically for GS2070 series drawer slides installed in face-frame cabinets. It anchors the back end of the slide to the cabinet interior, giving the slide the rear support it needs where the cabinet side is recessed behind the face frame.
Face-frame cabinets set the cabinet side back from the front opening, which means the rear end of a drawer slide hangs unsupported unless a bracket carries it. This bracket solves that problem for GS2070 slides: it closes the gap between the slide's rear end and the back panel, keeping the slide level and aligned across the full length of travel. Without it, a GS2070 slide in a face-frame cabinet would lack rear support and the drawer would sag or rack over time. If the cabinets on the job are frameless, the slide mounts directly to the side panel and this bracket is not required.
The bracket is molded from plastic, which keeps it light and immune to the moisture and humidity common inside a closed cabinet. The dowel-mount design presses into a bored hole in the cabinet back or rear rail, seating quickly and holding position without screws at the mounting point. Because this bracket is engineered for the GS2070 series specifically, do not substitute it for rear brackets from other slide families — bracket geometry is series-matched and parts from different programs will not seat correctly on the GS2070 slide body.
This bracket is an add-on accessory for shops and installers running GS2070 slides into face-frame cabinetry. Production cabinet shops building face-frame lines and contractors retrofitting drawers into existing framed cases both reach for rear brackets on every opening. If a project mixes face-frame and frameless cabinets, rear brackets are needed only on the face-frame runs. Order one bracket per slide — two per drawer opening.
Only for face-frame cabinets. In frameless construction the slide mounts directly to the side panel along its full length, so no rear bracket is needed. In a face-frame cabinet the rear of the slide cannot reach the recessed side panel, and the bracket is required.
No. This bracket is matched to the GS2070 series slide body. Rear brackets are series-specific — the clip geometry, depth, and mounting position differ between programs, and a bracket from another series will not seat correctly on a GS2070 slide.
The bracket has a dowel that presses into a bored hole in the cabinet's rear rail or back panel. No screw is needed at the dowel point — the bore holds the bracket in position while the slide locks into the bracket's clip or socket.
One bracket per slide, so two brackets per drawer opening — one on the left and one on the right.
The right rear bracket turns a face-frame opening into a clean, fully supported GS2070 installation — no sag, no racking, no second trip back to the job.
Sold In: 1 Each
