The Cantek PCS24 24" Left Hand Pneumatic Cut-Off Saw is a high-performance solution designed to enhance efficiency and safety in crosscutting operations. Powered by a robust 15HP motor, this saw delivers precise and consistent cuts across a variety of materials and dimensions. Its pneumatic foot pedal operation allows for smooth, hands-free control, while multiple safety features ensure a secure working environment. With an adjustable cutting stroke and a precision-ground cast iron table, the PCS24 provides superior cutting accuracy and reliability, making it an ideal choice for high-production workshops.
Key Features & Benefits
Enhanced Safety with Multiple Protective Features
• Infeed and outfeed safety guards protect operators from accidental contact.
• Microswitches on all access doors prevent operation when doors are open.
• Security bolt on the saw access door ensures additional protection during use.
Superior Cutting Versatility with Adjustable Capabilities
• Large cutting capacity accommodates a wide range of material dimensions from 2"x21" to 7"x8".
• Adjustable cutting stroke optimizes cutting speed and quality for different applications.
• Fast cutting cycle delivers up to 40 strokes per minute for maximum productivity.
Streamlined Operation for Maximum Efficiency
• Pneumatic foot pedal allows for smooth, hands-free operation and better workflow.
• Optional dual push-button control provides an alternative operation method for enhanced safety.
• Precision-ground cast iron table ensures stability and accuracy for clean, precise cuts.
Reliable and Durable Construction
• Heavy-duty 15HP motor delivers consistent power for demanding cutting tasks.
• CSA/UL magnetic switch ensures reliable electrical performance and safety compliance.
• Adjustable material clamp securely holds workpieces of varying thickness for improved accuracy.
- Air Consumption: 27.5 CFM
- Air Requirements: 27.5 CFM
- Arbor Diameter: 1"
- Blade Size: 24"
- Blade Speed: 2400 RPM
- Cutting Capacity: 2" x 21", 4" x 19", 6" x 15", 7" x 8"
- Cycle Operation: Air / mechanical
- Cycle Speed: 40 Strokes/min
- Electrical Requirements: 460/3/60 = 21 Amps
- Gross Weight: 1433 lbs
- Net Weight: 1058 lbs
- Saw Arbor Diameter: 1"
- Saw Blade Speed: 2400 RPM
