Vionaro H249 Drawer Slide, 9-3/4", Silver Gray, 18

Vionaro H249 Drawer Slide For Precise Cabinets

Vionaro H249 drawer slide describes a Grass America component from the Grass Vionaro Drawer System designed around a cubist design with 90 degree angles, so drawer sides present clean, straight lines in modern cabinetry. The slimline 13 mm, or 1/2 inch, side width keeps drawer walls thin, which preserves internal storage space while maintaining the visual look of a fine-line metal drawer. This 18 inch drawer slide works within the Vionaro drawer construction system, so it serves as a core structural and motion element rather than an add-on runner. The bottom panel is cut to size without notching, which streamlines panel processing and helps support repeatable box construction on cabinet jobs.

Key Vionaro H249 Details For Shop Planning

• The cubist design with 90 degree angles produces square-edged drawer sides, which helps maintain a consistent visual line across a bank of cabinets where alignment matters.
• The slimline 13 mm, or 1/2 inch, side width keeps the drawer profile narrow, which allows more usable internal width when fitting storage into standard cabinet openings.
• Three dimensional adjustment built into the system provides integrated side and height adjustment, which helps fine-tune the drawer front position during install or later refinements.
• Tilt angle adjustment at the back adds another adjustment axis, which supports leveling the drawer front plane so stacked drawers read flat and aligned.
• Tool-free front assembly speeds attachment of the front, which is useful in production runs or on site where reducing assembly steps saves time.
• The front adapter with stabilizer ensures maximum stability on tall fronts, which helps tall drawer faces track smoothly and sit true under daily use.

Installation And Fit Details For This Slide

This Grass Vionaro H249 component is part of a drawer construction system that uses integrated side and height adjustment, so installers can shift fronts horizontally and vertically without changing the cabinet. The tilt angle adjustment at the back lets the user set the drawer face angle, supporting consistent reveals on frameless or frame cabinetry. A bottom panel cut to size without notching simplifies panel fabrication, because the panel follows straightforward dimensions instead of stepped corners. Tool-free front assembly connects the front to the system without separate fastening tools, which keeps assembly steps focused on alignment instead of hardware handling.

Using The Grass Vionaro H249 In Projects

Where This Vionaro Drawer Slide Fits Best

The Grass Vionaro H249 drawer slide in silver gray works within the Grass Vionaro Drawer System for both frame and frameless cabinetry, so a single system can carry across different box constructions in a project. The slimline 13 mm side width supports tight cabinet layouts, because drawers consume less width inside a fixed opening, which helps when planning storage inside standard carcasses. A cubist design with 90 degree angles complements straight-lined casework, so the drawer sides visually match flat-front door and drawer programs often used in modern kitchens or commercial fixtures. The front adapter with stabilizer supports maximum stability on tall fronts, which is valuable for high-front pantry drawers or deep storage where extra height can otherwise flex.

Adjustment Features That Support Accurate Results

The 3 dimensional adjustment built into this Grass America component, combining integrated side and height adjustment with tilt angle adjustment at the back, lets installers refine drawer front gaps after the box is built, which reduces rework on the cabinet itself. Side adjustment allows shifting the front left or right, useful for dialing in even spacing between adjacent fronts. Height adjustment moves the front up or down, so rails and adjacent faces line up across a run. Tilt angle adjustment at the back sets the vertical plane of the front, helping remove top or bottom edge taper in the reveals. Plus and minus adjustments for all dimensions give a defined range in each direction, so installers can plan clearances knowing that fine-tuning is built into the hardware. Tool-free front assembly supports this adjustment workflow, because fronts can be connected, checked against neighboring fronts, and then quickly released again to reset if needed. Compatibility with Dynapro 2D undermount slides means this Vionaro element can work with that undermount platform, and compatibility with Dynapro 3D undermount slides using a 3D adapter set extends that to a 3D Dynapro configuration, which ties the drawer system into proven undermount runners.

Common Questions About This Vionaro H249 Slide

Choose This Slide For Precise Vionaro Drawers

The Grass Vionaro H249 drawer slide, identified by manufacturer part F135135080207 and described as an 18 inch Vionaro H249, silver grey component, delivers a cubist 90 degree profile with slimline 13 mm sides, 3 dimensional adjustment, and tool-free front assembly. For projects using the Grass Vionaro Drawer System with Dynapro 2D or Dynapro 3D undermount slide platforms, this slide supports clean front alignment, efficient box construction, and consistent layout across frame and frameless cabinetry.
