SH-10 self closing concealed scissors hinge from Knape and Vogt is a sink tip out tray hinge that connects a false front to a tilt-out tray, so the front pivots smoothly instead of being fixed. The self-closing action pulls the tray front shut at the end of travel, which helps the front sit tight against the cabinet face in everyday use. This concealed hinge style hides the working hardware inside the cabinet, so only the false front and tray are visible when the job is complete. The hinge body is sized at 2-7/8 inches long, 1-7/8 inches deep, and 3-13/16 inches high, so installers can plan the cabinet interior layout around a known footprint. The nickel finish identifies the hardware easily during layout and matches common nickel-finished cabinet components in many shops.
The SH-10 self closing concealed scissors hinge is built with an internal stop and a specified 1mm minimum reveal at the top and bottom, which together control how the false front moves and seats. That reveal provides working clearance as the front pivots, reducing the chance of the edges rubbing the cabinet face during operation. Because the hinge fits both traditional frame and frameless cabinets, installers can position the front to align with face frames or panel edges using the same reveal guideline. The 2-7/8 inch by 1-7/8 inch by 3-13/16 inch hinge body defines the space required inside the sink cabinet, which helps during layout where plumbing and tray depth compete for room.
The SH-10 self closing concealed scissors hinge is used in sink tip out tray installations in kitchen and bath cabinets, turning a fixed false front into a functional tilt-out panel. As a product in the sink tip out trays and accessories class, it is intended to work as the hinge mechanism that connects the tray assembly to the cabinet face. The ability to fit both traditional frame cabinets and frameless cabinets means the same hinge model can be used in various cabinet lines within a shop. Its 2-7/8 inch length, 1-7/8 inch depth, and 3-13/16 inch height help define how deep a tray can be before interfering with the hinge swing or nearby plumbing inside the sink base. This sizing data lets installers coordinate the tray body and any adjacent components around the hinge movement path.
The self-closing function of the SH-10 hinge pulls the tip out front shut at the end of movement, which promotes a consistent closed position and reduces the need for frequent adjustment of the face alignment. Because the hinge is concealed, only the cabinet front and tray are visible, supporting clean finished work in kitchen and bath projects. The internal stop integrated into the hinge limits opening range, which helps keep the tray at a practical angle for access while avoiding over-extension stresses on the false front. The specified 1mm minimum reveal at the top and bottom provides a clear target when setting gaps, so installers can set up the front to swing freely without guesswork around clearance. The hinge dimensions also serve as a planning reference, supporting repeatable layouts from one sink cabinet to the next in a run.
The SH-10 is a self-closing concealed scissors hinge, so it pulls the tip out front shut and keeps the working parts hidden inside the cabinet for a clean exterior.
The SH-10 hinge is used on sink tip out tray installations, turning a false front in kitchen or bath cabinets into a tilt-out panel for tray access.
The SH-10 hinge fits both traditional frame cabinets and frameless cabinets, so it can be applied across multiple cabinet construction styles in one project.
The SH-10 hinge internal stop limits opening travel, setting a defined tip out angle that protects the front from over-rotation during daily operation.
The SH-10 1mm minimum reveal at top and bottom gives clearance for the false front to pivot, which reduces rubbing and helps maintain a tight, even gap.
The SH-10 hinge body measures 2-7/8 inches long, 1-7/8 inches deep, and 3-13/16 inches high, providing a clear footprint for planning interior cabinet space.
The Knape and Vogt SH-10 self closing concealed scissors hinge offers defined dimensions, an internal stop, and a 1mm minimum reveal specification, which together support planned fit for sink tip out tray projects. Its ability to work with both traditional frame and frameless cabinets lets installers rely on a single hinge model across different lines. For cabinet shops and serious DIY users laying out sink tip out trays, these characteristics provide a clear basis for selecting the SH-10 hinge when a concealed, self-closing tip out solution is needed.
Sold In: 1 Pair
